Optimization exploration of polyurethane foam combined with head-neck-shoulder mask immobilization in nasopharyngeal carcinoma radiotherapy

Journal Of Modern Oncology[ISSN:1672-4992/CN:61-1415/R]

Issue:
2024 21
Page:
4139-4142
Research Field:
Publishing date:

Info

Title:
Optimization exploration of polyurethane foam combined with head-neck-shoulder mask immobilization in nasopharyngeal carcinoma radiotherapy
Author(s):
ZHOU Dan1; 2; 3; ZHANG Zhenyu4; GUAN Xiyin2; 3; 5; YOU Dan1; 2; 3; 6; LIANG Hongjiao4; XIA Tian1; 2; 3
Keywords:
polyurethane foam; head-neck-shoulder mask; nasopharyngeal carcinoma; CBCT; set-up errors
PACS:
R739.6
DOI:
10.3969/j.issn.1672-4992.2024.21.022
Abstract:
Objective:To discuss the possibility of optimizing the immobilization of polyurethane foam combined head-neck-shoulder mask in nasopharyngeal carcinoma radiotherapy.Methods:20 patients with primary nasopharyngeal carcinoma requiring irradiation of cervical lymph nodes were randomly selected and divided into 2 groups of 10 patients each.Patients in group A were immobilized by general headrest+polyurethane foam+head-neck-shoulder mask.Patients in group B were immobilized by polyurethane foam+head-neck-shoulder mask.CBCT scans were performed before the first 3 radiotherapy sessions and once a week thereafter.The position verification centered on the skull base after scanning served as the data basis for IGRT.For patients with head and neck set-up errors exceeding 3 mm,repositioned and CBCT scanned again for treatment.Using the CBCT images from each initial scan,offline registration was used to obtain the set-up errors in the X（lateral）,Y（longitudinal）,and Z（vertical） directions with the head and neck as the center,which were used as the data for this study.Results:Set-up errors in the X,Y,and Z directions of head and neck in group A were(0.12±0.10)cm & (0.17±0.13)cm,(0.17±0.14)cm & (0.19±0.16)cm,and (0.18±0.15)cm & (0.22±0.16)cm,and the differences were all statistically significant(P<0.05).Set-up errors in the X,Y,and Z directions of head in group A and B were (0.12±0.10)cm & (0.15±0.16)cm,(0.17±0.14)cm & (0.17±0.16)cm,and (0.18±0.15)cm & (0.22±0.16)cm,and none of the differences were statistically significant(P＞0.05).Set-up errors in the X,Y,and Z directions of neck in group A and B were (0.17±0.13)cm & (0.25±0.21)cm,(0.19±0.16)cm & (0.22±0.16)cm,and (0.22±0.16)cm & (0.22±0.16)cm.The difference in the X direction was statistically significant(P<0.05),and the differences in the Y and Z directions were not statistically significant(P>0.05).Conclusion:The use of general headrest+polyurethane foam+head-neck-shoulder mask immobilization system for nasopharyngeal carcinoma radiotherapy patients improved the positional reproducibility of neck,but failed to solve the problem of greater error in the neck compared with the head.

References:

［1］SIEGEL RL,MILLER KD,JEMAL A,et al.Cancer statistics,2024［J］.CA Cancer J Clin,2024,70(1):7-30.
［2］龚蔷，傅深，薛梅，等.兆伏级锥形束CT引导的鼻咽癌放射治疗过程中的摆位精度分析［J］.现代肿瘤医学，2012,20(5):1027-1031.GONG Q,FU S,XUE M,et al.Megavoltage cone-beam CT-guided radiation therapy of nasopharyngeal carcinoma in the process of positioning precision［J］.Modern Oncology,2012,20(5):1027-1031.
［3］杨鸿昇，吴春如，张远，等.发泡胶联合热塑膜对头颈部肿瘤放疗患者CT定位舒适度和摆位精度的影响［J］.现代医用影像学，2023,32(9):1646-1658.YANG HS,WU CR,ZHANG Y,et al.The effect of polyurethane foam combined with thermoplastic film on CT positioning comfort and set-up accuracy in patients with head and neck tumor radiotherapy［J］.Modern Medical Imageology,2023,32(9):1646-1658.
［4］蒋思思，倪敏，刘利斌，等.发泡胶个体化头枕在头颈部肿瘤患者调强放射治疗中的应用［J］.医疗装备，2020,33(24):58-59.JIANG SS,NI M,LIU LB,et al.Application of polyurethane foam adhesive headrests in IMRT for patients with head and neck tumors［J］.Medical Equipment,2020,33(24):58-59.
［5］张雷，段诗苗，孙谦.发泡胶联合热塑膜在头颈部肿瘤放疗中的应用研究［J］.重庆医学，2021,50(12):2054-2056.ZHANG L,DUAN SM,SUN Q.Study on application of styrofoam combined with thermoplastic film in radiotherapy for head and neck tumor［J］.Chongqing Medicine,2021,50(12):2054-2056.
［6］陆维，许婷婷，许青，等.应用CBCT、EPID研究鼻咽癌2种体位固定方式摆位误差的比较分析［J］.中国癌症杂志，2014,24(7):535-539.LU W,XU TT,XU Q,et al.Comparison of set-up errors detected by EPID and CBCT using two different immobilization techniques for patients with nasopharygeal carcinoma［J］.China Oncology,2014,24(7):535-539.
［7］熊文敏，谢琛，罗晗，等.应用CBCT技术测量分析鼻咽癌VMAT治疗期间每周分次间及不同部位的摆位误差［J］.实用癌症杂志，2021,36(11):1894-1897.XIONG WM,XIE C,LUO H,et al.CBCT technique in the measurement of the setup errors between different times and different parts of nasopharyngeal carcinoma during VMAT treatment［J］.The Practical Journal of Cancer,2021,36(11):1894-1897.
［8］李果，袁太泽，陈晨，等.鼻咽癌调强放疗期间的急性放射性反应与体重下降的相关性［J］.实用医学杂志，2017,8(6):1216-1219.LI G,YUAN TZ,CHEN C,et al.The correlation between acute radiation response and weight loss during IMRT for nasopharyngeal carcinoma［J］.The Journal of Practical Medicine,2017,8(6):1216-1219.
［9］林承光，林刘文，刘秉梯，等.鼻咽癌三维适形和调强放疗中头部与颈部摆位误差比较研究［J］.中华放射肿瘤学杂志，2011,20(4):322-325.LIN CG,LIN LW,LIU BT,et al.Comparison of head and neck set-up errors in 3D conformal and IMRT for nasopharyngeal carcinoma［J］.Chinese Journal of Radiation Oncology,2011,20(4):322-325.
［10］薛青，陆维，张艳俊，等.探讨不同固定方式在鼻咽癌放疗中的应用［J］.肿瘤预防与治疗，2019,32(1):67-71.XUE Q,LU W,ZHANG YJ,et al.Application of different immobilization techniques in cone beam CT guided radiotherapy for nasopharyngeal carcinoma［J］.Journal of Cancer Control and Treatment,2019,32(1):67-71.
［11］苏霁清.CBCT在鼻咽癌调强放射治疗不同配准部位获得的摆位误差差异研究［D］.长沙:中南大学，2013:11-14.SU JQ.A study on difference of setup errors in CBCT on different registrations in intensity modulated radiotherapy of nasopharyngeal carcinoma［D］.Changsha:Central South University,2013:11-14.
［12］梁锋攀.鼻咽癌放射治疗的相关研究进展［J］.癌症进展，2021,19(10):988-990.LIANG FP.Research progress on radiotherapy for nasopharyngeal carcinoma［J］.Oncology Progress,2021,19(10):988-990.
［13］林桐，张静静，李娜娜.发泡胶在头颈部肿瘤患者调强治疗中的应用及对位移误差的影响［J］.重庆医学，2020,49(20):3441-3444.LIN T,ZHANG JJ,LI NN.Application of styrofoam in intensity modulation treatment of head and neck tumors and its effect on shifting error［J］.Chongqing Medicine,2020,49(20):3441-3444.
［14］杨晓梅，金建华，吴建亭，等.头颈部肿瘤精确放射治疗个体化固定技术临床应用［J］.生物医学工程与临床，2019,23(4):452-455.YANG XM,JIN JH,WU JT,et al.Clinical application of individualized fixation for precise radiotherapy in head and neck tumors［J］.Biomedical Engineering and Clinical Medicine,2019,23(4):452-455.
［15］王宇留，方涌文，林晓生，等.基于CBCT分析三种体位固定技术在盆腔肿瘤放疗中的应用比较［J］.现代肿瘤医学，2023,31(17):3237-3242.WANG YL,FANG YW,LIN XS,et al.Comparison of the application of three postural fixation techniques in pelvic tumor radio-therapy based on CBCT［J］.Modern Oncology,2023,31(17):3237-3242.
