The value of high-frame-rate contrast-enhanced ultrasound qualitative features combined with quantitative parameters in identifying benign and malignant prostate disease

Journal Of Modern Oncology[ISSN:1672-4992/CN:61-1415/R]

Issue:
2024 19
Page:
3725-3731
Research Field:
Publishing date:

Info

Title:
The value of high-frame-rate contrast-enhanced ultrasound qualitative features combined with quantitative parameters in identifying benign and malignant prostate disease
Author(s):
LI Yu1; 2; DAN Siyu1; LUO Jiping1; YANG Fang1; HE Xiuli1; HE Ling3; SHUAI Hui4; YUE Wensheng1
Keywords:
prostate cancer; contrast-enhanced ultrasound; high frame rate; qualitative features; quantitative analysis
PACS:
R737.25
DOI:
10.3969/j.issn.1672-4992.2024.19.017
Abstract:
Objective:To investigate the value of high frame rate contrast-enhanced ultrasound(H-CEUS) qualitative features combined with quantitative parameters for the differential diagnosis of benign and malignant prostate lesions.Methods:Sixty patients(67 lesions in total) were enrolled from February 2022 to January 2023,who presented to our hospital of North Sichuan Medical College with suspected prostate cancer(PCa) and underwent prostate biopsy.According to the pathological results,divided into benign and malignant groups.Conventional transrectal ultrasound(TRUS) and H-CEUS were performed before biopsy,to record the basic prostate appearance,qualitative characteristics and time intensity curve to obtain quantitative analysis parameters,and compare the difference.With pathological results used as the "gold standard" to develop receiver operating characteristic curves(ROC),application of the Z test to compare the diagnostic efficacy of H-CEUS qualitative and quantitative parameters alone and combined for the diagnosis of benign and malignant prostate lesions.Results:Compared with the benign group,H-CEUS imaging in the malignant group was characterized by a greater proportion of irregular blood-supplying arterial shaped(1/33 vs 11/34),and abnormalities of alignment(3/33 vs 20/34),fast-enhancement(9/33 vs 29/34),hyper-enhancement(4/33 vs 25/34),and contrast distribution in homogeneity(9/33 vs 13/34),the differences were statistically significant(χ2 =30.41,18.37,22.96,25.72,8.06,P<0.001,<0.001,<0.001,<0.001,<0.001,=0.005).Quantitative analysis of parameters malignant than benign group contrast arrival time was earlier［(16.93±3.69)s vs (21.54±3.86)s］,peak intensity was higher［(48.8±5.58)dB vs (45.77±4.42)dB］,the value of intensity difference［4.87(0.87,8.03) vs -0.44(-2.22,2.35)］ and intensity ratio［(1.15±0.24) vs (1.01±0.97)］were greater than those of benign,with statistically significant differences(t/U=4.24,-2.324,151,-2.535，P＜0.001,=0.025,=0.004,=0.015).The ROC curve showing AUC=0.938 for the combined diagnosis of H-CEUS，best diagnostic efficacy was achieved at a cut-off value of 0.44,with Yoden’s index,sensitivity,specificity,accuracy,positive predictive value and negative predictive value of 0.750,89.29%,85.71%,87.75%,89.3% and 85.7%.Based on the NRI,the combined diagnostic on qualitative features and quantitative parameters were positively improved (P＜0.05).Conclusion:The application of H-CEUS to the prostate provides differential diagnosis of benign and malignant prostate diseases by observing details of the contrast perfusion and analyzing the qualitative features,and the diagnostic efficacy of combining the imaging perfusion features with quantitative parameters is superior to that of applying alone.

References:

［1］顾佳敏,朱聪,訾豪,等.1990-2019年中国良性前列腺增生疾病负担分析［J］.解放军医学杂志,2021,46(10): 984-988.GU JM,ZHU C,ZI H,et al.Analysis of the disease burden of benign prostatic hyperplasia in China from 1990 to 2019［J］.Medicine Journal of Chinese People’s Liberation Army,2021,46(10):984-988.
［2］XIA C,DONG X,LI H,et al.Cancer statistics in China and United States,2022:profiles,trends,and determinants［J］.Chinese Medical Journal,2022,135(5):584-590.
［3］MOTTET N,VAN DEN BERGH RCN,BRIERS E,et al.EAU-EANM-ESTRO-ESUR-SIOG guidelines on prostate cancer-2020 update［J］.European Urology,2021,79(2):243-262.
［4］BAUR ADJ,SCHWABE J,ROGASCH J,et al.A direct comparison of contrast-enhanced ultrasound and dynamic contrast-enhanced magnetic resonance imaging for prostate cancer detection and prediction of aggressiveness［J］.European Radiology,2018,28(5):1949-1960.
［5］KANEKO M,LENON MSL,STORINO RAMACCIOTTI L,et al.Multiparametric ultrasound of prostate:role in prostate cancer diagnosis［J］.Therapeutic Advances in Urology,2022,14: 17562872221145625.
［6］ZHU L,LI N,ZHU Y,et al.Value of high frame rate contrast enhanced ultrasound in gallbladder wall thickening in non-acute setting［J］.Cancer Imaging:The Official Publication of the International Cancer Imaging Society,2024,24(1):7.
［7］FEI X,HAN P,JIANG B,et al.High frame rate contrast-enhanced ultrasound helps differentiate malignant and benign focal liver lesions［J］.Journal of Clinical and Translational Hepatology,2022,10(1):26-33.
［8］梁舒媛,罗渝昆,费翔,等.高帧频超声造影在鉴别浅表淋巴结性质中的应用［J］.中华医学超声杂志（电子版）,2020,17(9):841-847.LIANG SY,LUO YK,FEI X,et al.Clinical application of high-frame-rate contrast-enhanced ultrasound in differentiation of benign and malignant superficial lymph nodes［J］.Chinese Journal of Medical Ultrasound(electronic edition),2020,17(9):841-847.
［9］赫捷,陈万青,李霓,等.中国前列腺癌筛查与早诊早治指南（2022，北京）［J］.中国肿瘤,2022,31(01):1-30.HE J,CHEN WQ,LI N,et al.China guideline for the screening and early detection of prostate cancer(2022,Beijing)［J］.China Cancer,2022,31(01):1-30.
［10］SALIB A,HALPERN E,EISENBREY J,et al.The evolving role of contrast-enhanced ultrasound in urology:a review［J］.World Journal of Urology,2023,41(3):673-678.
［11］KURU TH,FTTERER JJ,SCHIFFMANN J,et al.Transrectal ultrasound (US),contrast-enhanced us,real-time elastography,histoscanning,magnetic resonance imaging (MRI),and MRI-US fusion biopsy in the diagnosis of prostate cancer［J］.European Urology Focus,2015,1(2):117-126.
［12］DIETRICH CF,AVERKIOU M,NIELSEN MB,et al.How to perform contrast-enhanced ultrasound(CEUS)［J］.Ultrasound International Open,2018,4(1):E2-E15.
［13］Health Commission of The People’s Republic of China.National guidelines for diagnosis and treatment of prostate cancer 2022 in China(English version)［J］.Chinese Journal of Cancer Research,2022,34(3):270-288.
［14］SIDHU PS,CANTISANI V,DIETRICH CF,et al.The EFSUMB guidelines and recommendations for the clinical practice of contrast-enhanced ultrasound(CEUS) in non-hepatic applications:Update 2017 (Short Version)［J］.Ultraschall in Der Medizin (Stuttgart,Germany:1980),2018,39(2):154-180.
［15］XIE SW,DONG BJ,XIA JG,et al.The utility and limitations of contrast-enhanced transrectal ultrasound scanning for the detection of prostate cancer in different area of prostate［J］.Clinical Hemorheology and Microcirculation,2018,70(3):281-290.
［16］韩鹏,费翔,罗渝昆,等.高帧频超声造影在鉴别诊断胆囊腺瘤性息肉与胆固醇性息肉中的临床应用［J］.中华医学超声杂志（电子版）,2020,17(9):815-820.HAN P,FEI X,LUO YK,et al.Value of clinical application of high-frame-rate contrast-enhanced ultrasound in distinguishing gallbladder adenomas from cholesterol polyps［J］.Chinese Journal of Medical Ultrasound (Electronic Edition),2020,17(9):815-820.
［17］TYLOCH JF, WIECZOREK AP.The standards of an ultrasound examination of the prostate gland［J］.Journal of Ultrasonography,2017,17(68):43-58.
［18］FEI X,LI N,ZHU L,et al.Value of high frame rate contrast-enhanced ultrasound in distinguishing gallbladder adenoma from cholesterol polyp lesion［J］.European Radiology,2021,31(9):6717-6725.
［19］JUNG EM,WIGGERMANN P,GREIS C,et al.First results of endocavity evaluation of the microvascularization of malignant prostate tumors using contrast enhanced ultrasound (CEUS) including perfusion analysis:first results［J］.Clinical Hemorheology and Microcirculation,2012,52(2-4):167-177.
［20］YANG W,ZHOU J,YUE C,et al.Clinical value of contrast-enhanced ultrasound quantitative analysis for differentiating thyroid lesions in Hashimoto’s thyroiditis patients［J］.Quantitative Imaging in Medicine and Surgery,2024,14(1):944-957.
［21］HONG H,LIANG D,LIU Q,et al.Value of transrectal contrast-enhanced ultrasound with clinical indicators in the prediction of bone metastasis in prostate cancer［J］.Quantitative Imaging in Medicine and Surgery,2022,12(3):1750-1761.
［22］MAXEINER A,FISCHER T,SCHWABE J,et al.Contrast-enhanced ultrasound(CEUS) and quantitative perfusion analysis in patients with suspicion for prostate cancer［J］.Ultraschall in Der Medizin (Stuttgart,Germany:1980),2019,40(3):340-348.

Memo

Memo:
四川省南充市应用基础研究项目(编号：22YYJCYJ0052)
Last Update: 2024-08-30
