Title:

Preparation and in vitro cell imaging study of fluorescent probe liposomes responsive to myeloperoxidase

Author(s):

DUAN Jiangbo¹; 2; TAO Jianlin³; ZHU Jiang⁴; HOU Yiling¹; 2

Keywords:

myeloperoxidase; luminol; Cy5; fluorescent probe liposomes; cell imaging

PACS:

R741.044

DOI:

10.3969/j.issn.1672-4992.2024.21.003

Abstract:

Objective:To prepare luminol-Cy5 fluorescent probe liposomes which responsive to myeloperoxidase,optimize the preparation process and explore the in vitro cell imaging effect.Methods:Using lecithin,cholesterol,and collagen as raw materials of liposomes,luminol-Cy5 fluorescent probe liposomes were prepared by thin film hydration method.The preparation process was optimized using single factor analysis and response surface methodology.At the same time,RAW264.7 mouse macrophage cells that showed inflammation after LPS stimulation were used as the model to explore the cellular imaging effect of fluorescent probe liposomes responsive to myeloperoxidase.Results:The results showed that when the mass ratio of luminol to Cy5 was 2¡Ã1,the film material ratio was 4¡Ã1 and the hydration temperature was 40 ¡æ,the fluorescence probe liposome encapsulation effect was the best,with a luminol encapsulation efficiency of 57.26% and a Cy5 encapsulation efficiency of 60.22%.The average particle size of luminol-Cy5 fluorescent probe liposome was 205.01 nm,and the Zeta potential was -30.41 mV.The cell imaging results showed that in RAW264.7 mouse macrophages stimulated by LPS,luminol in the fluorescent probe liposome was able to respond to myeloperoxidase activity and emit blue fluorescence.At the same time,this blue fluorescence could stimulate Cy5 in the fluorescent liposome to emit red fluorescence at 677 nm,achieving imaging detection of deep inflammatory cells.Conclusion:Luminol-Cy5 fluorescent probe liposomes could respond to myeloperoxidase in vitro and achieve imaging detection of deep inflammatory cells through bioluminescence resonance energy transfer (BRET).They had certain application value in the evaluation and treatment of inflammatory reactions caused by tumors and epilepsy.

References:

£Û1£ÝGORUDKO IV,GRIGORIEVA DV,SOKOLOV AV,et al.Neutrophil activation in response to monomeric myeloperoxidase£ÛJ£Ý.Biochemistry and Cell Biology,2018,96(5):592-601.
£Û2£ÝMETZLER KD,FUCHS TA,NAUSEEF WM,et al.Myeloperoxidase is required for neutrophil extracellular trap formation:implications for innate immunity£ÛJ£Ý.Blood,2011,117(3):953-959.
£Û3£ÝPANG Y,WU L,TANG C,et al.Autophagy-inflammation interplay during infection:balancing pathogen clearance and host inflammation£ÛJ£Ý.Frontiers in Pharmacology,2022,13(1):832750-832761.
£Û4£ÝKORNILUK A,KOPER O,KEMONA H,et al.From inflammation to cancer£ÛJ£Ý.Irish Journal of Medical Science,2017,186(1):57-62.
£Û5£ÝKATO Y.Neutrophil myeloperoxidase and its substrates:formation of specific markers and reactive compounds during inflammation£ÛJ£Ý.Journal of Clinical Biochemistry and Nutrition,2016,58(2):99-104.
£Û6£ÝLIU JH,CHEN J,QIN S,et al.Application of infrared spectroscopy in microalgal research£ÛJ£Ý.Spectroscopy and Spectral Analysis,2019,39(1):79-86.
£Û7£ÝLIU XS,ZHANG SY,SI LT,et al.A combination of near infrared and mid-infrared spectroscopy to improve the determination efficiency of active components in radix astragali£ÛJ£Ý.Journal of Near Infrared Spectroscopy,2020,28(1):10-17.
£Û8£ÝZHANG M,JIANG J,CAI M,et al.Electrochemical modulation of the fluorescence of cyanine dye Cy5£ÛJ£Ý.Electroanalysis,2015,27(8):1817-1822.
£Û9£ÝGRACHEVA IA,TRETIAKOVA DS,ZAMYSHLYAEVA OG,et al.Cy5-labeled phosphatidylcholine£ÛJ£Ý.Russian Journal of Bioorganic Chemistry,2021,47(5):1114-1117.
£Û10£ÝTHIRUKKUMARAN OM,WANG CR,ASOUZU NJ,et al.Improved HaloTag ligand enables BRET imaging with NanoLuc£ÛJ£Ý.Frontiers In Chemistry,2020,7(1):938-944.
£Û11£ÝRAHIMPOUR Y,HAMISHEHKAR H.Liposomes in cosmeceutics£ÛJ£Ý.Expert Opinion on Drug Delivery,2012,9(4):443-455.
£Û12£ÝZHANG T,XU X,PAN Y,et al.Specific surface modification of liposomes for gut targeting of food bioactive agents£ÛJ£Ý.Comprehensive Reviews in Food Science and Food Safety,2023,22(5):3685-3706.
£Û13£ÝANTONIOU AI,GIOFR¦K S,SENECI P,et al.Stimulus-responsive liposomes for biomedical applications£ÛJ£Ý.Drug Discovery Today,2021,26(8):1794-1824.
£Û14£ÝMUSIELAK M,POTOCZNY J,BO¦l-LIEDKE A,et al.The combination of liposomes and metallic nanoparticles as multifunctional nanostructures in the therapy and medical imaging-a review£ÛJ£Ý.International Journal of Molecular Sciences,2021,22(12):6229-6252.
£Û15£Ýº«Åô£¬ÍôÑó£¬Öì±ó.È«·ú¼ºÍéÖ¬ÖÊÌåÄÉÃ×Á£ÔÚ³¬ÉùÔìÓ°·½Ãæ¼ÛÖµµÄʵÑéÑо¿£ÛJ£Ý.ÏÖ´úÖ×Áöҽѧ£¬2018,26£¨19£©£º3038-3042.HAN P,WANG Y,ZHU B.The application assessment of perfluorohexane based liposome nanoparticles on ultrasound enhanced imaging£ÛJ£Ý.Modern Oncology£¬2018,26£¨19£©£º3038-3042.
£Û16£ÝGHARIB R,GREIGE-GERGES H,FOURMENTIN S,et al.Liposomes incorporating cyclodextrin-drug inclusion complexes:Current state of knowledge£ÛJ£Ý.Carbohydrate Polymers,2015,129(1):175-186.
£Û17£ÝROZO AJ,COX MH,DEVITT A,et al.Biophysical analysis of lipidic nanoparticles£ÛJ£Ý.Methods,2020,180(1):45-55.
£Û18£ÝAGUIRRE-CRUZ G,LE¦„N-L¦„PEZ A,CRUZ-G¦„MEZ V,et al.Collagen hydrolysates for skin protection:oral administration and topical formulation£ÛJ£Ý.Antioxidants,2020,9(2):181-199.
£Û19£ÝWALTERS BD,STEGEMANN JP.Strategies for directing the structure and function of three-dimensional collagen biomaterials across length scales£ÛJ£Ý.Acta Biomaterialia,2014,10(4):1488-1501.
£Û20£ÝBRETAUD S,NAUROY P,MALBOUYRES M,et al.Fishing for collagen function:About development,regeneration and disease£ÛJ£Ý.Seminars in Cell and Developmental Biology,2019,89(1):100-108.
£Û21£ÝÍõ·¼,лÌðÌð.Öí·ô½ºÔ­µ°°×ëÄÖ¬ÖÊÌåµÄÖƱ¸¼°ÆäÖÊÁ¿ÆÀ¼Û£ÛJ£Ý.º£Ï¿Ò©Ñ§,2020,32(04):16-19.WANG F,XIE TT.Preparation and quality evaluation of pig skin collagen peptide liposomes£ÛJ£Ý.Strait Pharmacy,2020,32(04):16-19.
£Û22£ÝÑîÃÀÑà,ÀîìÏÃÉ,÷Ð˹ú.°ÂɳÀû²¬³¤Ñ­»·ÈÈÃôÖ¬ÖÊÌåµÄ°ü·âÂʲⶨ¼°ÌåÍâÊÍ·Å¿¼²ì£ÛJ£Ý.¾üÊÂҽѧ¿ÆѧԺԺ¿¯,2007,5(1):448-450.YANG MY,LI YM,MEI XG.Determination of encapsulation efficiency and in vitro release of oxaliplatin long cycle thermosensitive liposomes£ÛJ£Ý.Journal of The Academy of Military Medical Sciences,2007,5(1):448-450.
£Û23£ÝJIANG SH,LI DQ,ZHOU CB,et al.Capabilities of stochastic response surface method and response surface method in reliability analysis£ÛJ£Ý.Structural Engineering and Mechanics,2014,49(1):111-128.
£Û24£ÝRODRIGUES S,FERREIRA F,DIAS S.Liver abscess complicated with an inflammatory myofibroblastic tumor£ÛJ£Ý.Journal of the Belgian Society of Radiology,2022,106(1):78-81.
£Û25£ÝHONG CW.Extracellular vesicles of neutrophils£ÛJ£Ý.Immune Network,2018,18(6):43-51.
£Û26£ÝÒóÀ¤£¬È¨ê¿£¬Àî½Ü£¬µÈ.Ö×ÁöÏà¹ØÐÔÑ×Ö¢ÔÚÏû»¯µÀÖ×ÁöÖеÄ×÷Óü°»úÖÆÑо¿½øÕ¹£ÛJ£Ý.ÏÖ´úÖ×Áöҽѧ£¬2023,31£¨19£©£º3684-3688.YIN K,QUAN X,LI J,et al.Research progress on the role and mechanism of tumor-related inflammation in digestive tract tumors£ÛJ£Ý. Modern Oncology£¬2023,31£¨19£©£º3684-3688.
£Û27£ÝARNHOLD J.The dual role of myeloperoxidase in immune response£ÛJ£Ý.International Journal of Molecular Sciences,2020,21(21):8057-8084.
£Û28£ÝSCANDOLARA TB,SILVA JC,MALANOWSKI J,et al.Anti-neutrophil antibodies (anti-MPO-ANCAs) are associated with poor prognosis in breast cancer patients £ÛJ£Ý.Immunobiology,2020,225(6):152011-152017.
£Û29£ÝTANNICH F,TLILI A,PINTARD C,et al.Activation of the phagocyte NADPH oxidase/NOX2 and myeloperoxidase in the mouse brain during pilocarpine-induced temporal lobe epilepsy and inhibition by ketamine£ÛJ£Ý.Inflammopharmacology,2020,28(2):487-497.
£Û30£ÝÕÔÑŲ¨£¬ÍõÔªÓ£¬ãÆСÁú.¹ýÑõ»¯ÎïøÌåÔöÖ³ÎＤ»îÊÜÌå-¦Ãͨ¹ýµ÷½ÚÑ×Ö¢ÖÎÁÆÖ×ÁöµÄÑо¿½øÕ¹£ÛJ£Ý.ÏÖ´úÖ×Áöҽѧ£¬2024,32£¨4£©£º777-782.ZHAO YB,WANG YY,YAN XL.Advances in peroxisome proliferator-activated receptor-¦Ã for the treatment of cancer through modulation of inflammation£ÛJ£Ý.Modern Oncology£¬2024,32£¨4£©£º777-782.
£Û31£ÝKAWASHIMA S,ARIMURA Y,SANO K,et al.Immunopathologic co-localization of MPO,IgG,and C3 in glomeruli in human MPO-ANCA-associated glomerulonephritis£ÛJ£Ý.Clinical Nephrology,2013,79(4):292-301.
£Û32£ÝZELLER M,WANG CH,KELIHER EJ,et al.Myeloperoxidase PET imaging tracks intracellular and extracellular treatment changes in experimental myocardial infarction£ÛJ£Ý.International Journal of Molecular Sciences,2023,24(1):5704-5714.
£Û33£ÝZHANG C,LIU Y,SUN H,et al.Automated E-FRET microscope for dynamical live-cell FRET imaging£ÛJ£Ý.Journal of Microscopy,2019,274(1):45-54.
£Û34£ÝLIU RF,TANG J,XU YX,et al.Bioluminescence imaging of inflammation in vivo based on bioluminescence and fluorescence resonance energy transfer using nanobubble ultrasound contrast agent£ÛJ£Ý.ACS Nano,2019,13(5):5124-5132.
£Û35£ÝLIN B,XIAO F,JIANG J,et al.Engineered aptamers for molecular imaging£ÛJ£Ý.Chemical Science,2023,14(48):14039-14061.
£Û36£ÝGUIMAR¦AES D,CAVACO-PAULO A,NOGUEIRA E.Design of liposomes as drug delivery system for therapeutic applications£ÛJ£Ý.International Journal of Pharmaceutics,2021,601(15):120571-120585.
£Û37£ÝAIZIK G,WAISKOPF N,AGBARIA M,et al.Liposomes of quantum dots configured for passive and active delivery to tumor tissue£ÛJ£Ý.Nano Letters,2019,19(9):5844-5852.
£Û38£ÝXIAO X,WU T,CAO J,et al.Rational engineering of chromic material as near-infrared ratiometric fluorescent nanosensor for H2S monitoring in real food samples£ÛJ£Ý.Sensors and Actuators B:Chemical,2020,323(15):128707-128716.
£Û39£ÝSANDANARAJ B,GREMLICH H,KNEUER R,et al.Fluorescent nanoprobes as a biomarker for increased vascular permeability:implications in diagnosis and treatment of cancer and inflammation£ÛJ£Ý.Bioconjugate Chemistry,2010,21(1):93-101.
£Û40£ÝLEMESHKO VV.Competitive interactions of amphipathic polycationic peptides and cationic fluorescent probes with lipid membrane:Experimental approaches and computational model£ÛJ£Ý.Archives of Biochemistry and Biophysics,2014,545(1):167-178.
£Û41£ÝLIU W,YE A,LIU W,et al.Behaviour of liposomes loaded with bovine serum albumin during in vitro digestion£ÛJ£Ý.Food Chemistry,2015,175(1):16-24.
£Û42£ÝLI MY,LI M,LI XY,et al.Preparation,characterization and ex vivo skin permeability evaluation of type I collagen-loaded liposomes£ÛJ£Ý.International Journal of Nanomedicine,2023,18(1):1853-1871.
£Û43£ÝCHUN JY,MIN SG,JO YJ.Production of low molecular collagen peptides-loaded liposomes using different charged lipids£ÛJ£Ý.Chemistry and Physics of Lipids,2017,209(1):1-8.

Memo

Memo:

ËÄ´¨Ê¡ÖصãʵÑéÊÒ¿ª·Å¿ÎÌ⣨±àºÅ£º210023-01SZ£©£»ËÄ´¨Ê¡¿Æ¼¼ÌüÓ¦Óûù´¡ÃæÉÏÏîÄ¿£¨±àºÅ£º2022NSFSC0107£©£»ËÄ´¨Ê¡¿Æ¼¼Ìü¿Æ¼¼³É¹ûת»¯×ʽðÏîÄ¿£¨±àºÅ£º2022NZZJ0003£©
